● Servo Voltage Stabilizer · Single-Phase · Wall-Mount

The TSD Series. Stable power. No floor space required.

A compact, wall-mounted single-phase voltage regulator with servo motor precision. Accepts 90–260V AC and delivers a steady 220V ±2% — protecting every appliance in the room without taking up any floor space.

Output accuracy

±1%

Form factor

Wall-mount

Input range

90–260v

TSD Series

Core Features

Smart protection in a compact wall package.

The TSD takes everything you need in a voltage stabilizer and puts it in a wall-mounted format, saving floor space without sacrificing performance.

Wall-Mount Design

Installs directly on the wall, freeing up valuable floor and shelf space. Ideal for compact homes, apartments, offices, and server rooms where a vertical floor unit would be impractical.

Ultra-Wide Input: 90–260V

Handles the full extremes of Nigerian grid instability. Even when input drops to 90V, the TSD continues delivering stable 220V output — critical in areas with chronic under-voltage.

Servo Motor + Toroidal Transformer

Stepless, continuous voltage regulation with no relay switching gaps. The servo motor and toroidal transformer combination delivers the smoothest, most precise regulation available in a compact stabilizer.

Informative LED Display

A real-time LED display shows input voltage, output voltage, and system status at a glance — visible from across the room, no external monitoring required.

100% Copper Transformer

Full copper windings deliver lower heat generation, superior conductivity, and a significantly longer service life — even under continuous heavy load in hot, humid environments.

Real Output at Low Voltage

The 5 kVA model delivers 2,300W and the 10 kVA model delivers 4,800W even when input drops to 90V — keeping your appliances powered through the most severe brownouts.

Pure copper. No compromises.

We refuse aluminium imitations. Even at this size, every TSD is wound with 100% copper — the gold standard for conductivity, heat resistance, and decades of reliable service under continuous loads.

Conductivity

+ 0 %

Heat loss

- 0 %

Service life

0 yr+

Technical Sheet

The full specification.

Available in 5 kVA and 10 kVA wall-mount configurations.

Type

Single-phase servo voltage stabilizer (wall-mount)

Input voltage

90–260V AC

Input frequency

50 / 60 Hz

Output voltage

220V ±2%

Output frequency

50 / 60 Hz

Power factor

100%

Control type

Servo motor + toroidal transformer

Transformer material

100% copper

Efficiency (AC–AC)

90%

Protection

High/low voltage, short circuit (MCB), surge, temperature (optional)

Display

LED

Operating temperature

−5°C to +60°C

Humidity

<90%

Enclosure

IP45

Dimensions (L×B×H)

310 × 190 × 450 mm (both models)

Warranty

18 months

Technical Sheet

Capacity-specific specifications

Model	Power	Max output @ 90V input	Weight
TSD-5 kVA	5,000 VA / 5,000 W	2,300 W	14 kg
TSD-10 kVA	10,000 VA / 10,000 W	4,800 W	20 kg

Where it works

Protects everything in your space.

The compact wall-mount form makes the TSD ideal for any setting where a floor-standing unit isn’t practical.

Home Appliances

ACs, fridges, washing machines, TVs, home theatre, decoders, fans, microwaves.

Office Equipment

Computers, printers, photocopiers, desktops, servers, CCTV networks.

Telecom & Data

BTS towers, server rooms, data centers and critical network infrastructure.

Protect Your Devices

Order the SBW today.

Available in 5 kVA and 10 kVA. Our team will help you choose the right capacity for your home or office, with delivery available nationwide.
